Used for drying porous high-specific-surface-area materials such as aerogels and hydrogels, microbial treatment in antibiotic pharmaceutical, food, and pharmaceutical raw materials, medical material preparation, catalyst preparation, etc. Suitable for universities, research institutes, and enterprise laboratories.

Function

Better Use: Incorporating 27 years of supercritical drying process R&D experience into the equipment, allowing you to easily and freely realize various creative ideas and concepts.

Higher Safety: Multiple independent safety protections are set in parallel at key parameter points, combining high and low, “soft and hard” integration.

Small Footprint, can be placed on the ground or laboratory bench according to site conditions;

Direct observation of the sample condition during drying, timely adjustment of process parameters, accurate grasp of the experimental process, higher success rate of drying;

Easy research, user-friendly control interface, automatic control after parameter setting;

Precise flow injection, precise linear pressure relief, richer process optimization methods, more accurate data; non-destructive samples, higher success rate;

Lightweight feel, reliable sealing, comfortable body angles for personnel during observation, operation, and maintenance, reducing physical fatigue or injury of researchers, ensuring work efficiency;

More comprehensive control of the operating parameters at key nodes of the process, more diverse adjustment and optimization methods for results, accurate, true, and effective measurement and control data, good result reproducibility, guiding the transformation of results and the implementation of large-scale applications.

Modular design, free combination, subsequent expansion, modification, and upgrade at any time, expanding the applicable scope, increasing the service life of the instrument, continuously outputting and creating scientific research value for you;

Configuration Parameters:

Ø Maximum operating pressure up to 30MPa;

Ø Maximum operating temperature up to 220℃;

Ø Temperature control accuracy: ±0.5℃;

Ø Drying chamber optional 50ml, 100ml, 500ml, 1000ml, 5L, 10L, 20L, 29L, other volume specifications can be customized;

Ø 1～4 drying chambers can be provided in parallel for simultaneous processing, each channel's process parameters can be set and controlled independently, multi-channel parallel needs customization;

Ø Designed and configured according to 3 supercritical drying process implementation processes, other supercritical drying process implementations need customization;

Ø The medium is CO2 or ethanol, other supercritical drying medium instruments can be customized;

Ø The minimum medium injection volume can be between 0.01～6.99ml/min, the minimum adjustment step can be reduced to 0.01ml/min;

Ø Supercritical drying process control and safety protection system;

Ø Precise linear pressure relief function, up to 100h, longer time can be customized (optional);

Ø Mass flow meter (optional);

Ø Imported CO2 precision booster pump, flow range 0～50ml/min or 0～200ml/min, maximum pressure 10,000Psi (optional);

Ø British original imported pressure fine-tuning control needle valve (optional).
