Used for the efficient extraction, separation, or removal of edible oils, flavors, pigments, low-boiling-point volatile components, efficacy components of Chinese herbal medicine, heat-sensitive components, pesticide residues, heavy metal ions, organic pollutants, animal tissue fats, cell metabolites, proteins or enzymes, chemical mixtures; as well as for precise analysis and detection of various components in biomedical, food quality and safety, material research, environmental analysis, customs inspection, drug detection, forensic toxicology analysis, petrochemical, and other fields. Suitable for universities, research institutes, enterprises, and professional analysis and testing institutions.

Function

Ø Superior Performance: Incorporating over 38 years of supercritical extraction process R&D experience into the equipment, allowing you to freely realize various creative ideas and concepts.

Ø Higher Safety: Multiple independent safety protection measures are configured in parallel at key parameter nodes, achieving a combination of high and low, “soft and hard” integration.

Ø Compact Footprint: Flexible selection of ground or laboratory bench placement specifications, with the smallest instrument footprint of only 0.2m², directly connectable to conventional laboratory benches, significantly reducing deployment costs.

Ø Precise Separation: According to the physical and chemical properties of the target components, different separation and collection units are selected, resulting in more credible data and better reproducibility.

Ø Differentiated Design: Differentiated structural design for solid/liquid materials, making research results more authentic and of higher application value.

Ø Comfortable Experience: Lightweight feel, stable sealing, comfortable body angles for personnel during observation, operation, and maintenance, effectively reducing physical fatigue or injury of researchers, strongly ensuring work efficiency.

Ø Precise Measurement and Control: More comprehensive control of the operating parameters at key nodes of the process, more diverse adjustment and optimization methods for results, accurate, true, and effective measurement and control data, good result reproducibility, strongly guiding the transformation of results and the implementation of large-scale applications.

Ø Flexible Modules: Adopting functional modular design, allowing free combination, subsequent expansion, modification, and on-demand upgrades at any time, expanding the applicable scope, extending the service life of the instrument, and continuously outputting and creating scientific research value for you.

Configuration Parameters:

Ø Maximum operating pressure up to 68MPa (10,000psi);

Ø Maximum operating temperature up to 250℃;

Ø Temperature control accuracy: ±0.5℃;

Ø Extraction vessel volume optional 5ml, 10ml, 24ml, 32ml, 50ml, 100ml, 500ml, 1000ml, 5L, 10L, 20L, 29L, other volume specifications can be customized;

Ø The instrument is designed and configured according to supercritical extraction, supercritical entrainer extraction, liquid material supercritical extraction, supercritical distillation, and other processes, other supercritical extraction processes can be customized;

Ø The default extraction medium is CO2, other supercritical extraction media such as ethanol, methanol, propane, butane, or pentane can be customized.

Ø Electronic back pressure control (optional);

Ø Supercritical extraction process control system (optional);

Ø Mass flow meter (optional);

Ø Entrainer pump (optional);

Ø Entrainer injection management system (optional);

Ø Cylinder residual gas management module (optional);

Ø CO2 recovery and storage system (optional).
